50m Concrete Boom Pump Truck , Truck-Mounted Concrete Pumps, Concrete Placing Boom
Main Features
• Compact in design, 50m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, it monitors the pump intelligently on working data
management,real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual man-machine interface system
| Concrete Pump Information | Truck information of Concrete Pump | ||
| Type | BOOM CONCRETE PUMPS | Truck Brand | SCANIA |
| Brand Name | Zoomlion | Truck Model | P420 |
| Pump Model | ZLJ5402THB | Truck Year | 2010year |
| Pump Year | 2010year | VIN. | YS2P8X********* |
| Boom Length | 50METER | Axle Config | 4 Axle |
| Pump Hours | 3000 hours | Mileage | |
| Boom Section | 6 SECTIONS RZ FOLD | Truck Hours | |
| Vertical Reach | 50METER | Engine Make | SCANIA |
| Horizontal Reach | 46METER | Engine Type | Diesel |
| Max Concrete Output | 170/120m3/h | Engine Model | |
| Conrete Press. | 8.3/12 Mpa | Max.Engine Power | 300kw |
| Barrel Size | 500 L | Max.EngineTorque | |
| Radio Remote conctrol | concrete pump remote controller | Transmission | BENZ |
| Radio Remote Brand | remote controller HBC 719 | Max. Speeds | 80 km/h |
| Condition | concrete pump but well condition | Total Weight | 39870KG |
| Recent Significant | Excellent condition, low hours | Dimension(L*W*H) | 12900*2500*3980mm |
| Repairs | Concrete pumps system | Maintenance | Changed all filters |
| Hydraulic System | Engine oil | ||
| Electrical System | Gear box oil | ||
| Changed Spare Parts | Tires | ||
| Checked Boom | Cab | ||
| Changed Seals | Driving testing | ||
