ZOOMLION Concrete Boom Truck

ZOOMLION Concrete Boom Truck

  • Highlight

    ISO concrete boom truck

    ,

    ZOOMLION concrete boom truck

    ,

    ZOOMLION sitrak truck

  • Chassis Brand
    SITRAK
  • Condition
    Brand New
  • Power(w)
    331KW
  • Emission Standard
    Euro 5
  • Maximum Vertical Reach
    62.1m
  • Maximum Horizontal Reach(From Center Of Slewing Axis)
    56.9m
  • Section Numbers
    7.0
  • Minumun Unfolding Height
    15.8M
  • Boom Type
    RZ
  • Maximum Theorical Output
    180 CBM/h
  • Maximum Theorical Pressure On Concrete
    11.3Mpa
  • Concrete Cylinders (diam.*stroke)
    260*2100mm
  • Hydraulic Circuit
    Closed
  • Outrigger Open Dimension(mm)
    12250*12820*11660
  • Dimension
    13835*2550*4000mm
  • Weight
    43870kg
  • Place of Origin
    China
  • Brand Name
    ZOOMLION
  • Certification
    ISO/CE/SGS/BV
  • Model Number
    ZLJ5440THBKE 63X-7RZ
  • Minimum Order Quantity
    1
  • Price
    Negotiated
  • Packaging Details
    RORO ship, Cargo bulk ship
  • Delivery Time
    20 working days
  • Payment Terms
    T/T
  • Supply Ability
    5 units per month

ZOOMLION Concrete Boom Truck



Sitrak 8*4 Euro 5 New ZOOMLION Truck Mounted Concrete Pumps 63X-7RZ



Product highlights:



Unique 7-arm technology in the industry, the effective placing radius is 75% higher than the 6-arm structure;

ZOOMLION pump truck arm frame foot, limit height, 8% larger than the effective fabric range of the 66-meter pump truck;
The length of the whole machine is 13.8 m, 8% shorter than that of the same grade; the whole machine is improved by 17%, with smaller turning radius and better site adaptability;
High precision and efficient high pressure pumping technology, pumping efficiency is 8% higher than the industry
