A concrete pump is a time-, cost-, and back-saving machine that moves wet concrete to places where concrete mixer trucks cannot reach. There are two main types of concrete pumps—boom pumps and line pumps.
Both of these pumps can reach over, under, high up, deep down below, and far away from the concrete mixer trucks to pour concrete quickly and accurately.
| Concrete Pump Information | Truck information of Concrete Pump | ||
| Type | BOOM CONCRETE PUMPS | Truck Brand | Volvo |
| Brand Name | Putzmeister | Truck Model | Volvo 380 |
| Pump Model | SG5332THB42 | Truck Year | 2007 year |
| Pump Year | 2008year | VIN. | LZVABG************ |
| Boom Length | 42 METER | Axle Config | 4 Axle |
| Pump Hours | 4000 hours | Mileage | |
| Boom Section | 4 SECTIONS Z FOLD | Truck Hours | |
| Vertical Reach | 42 METER | Engine Make | Volvo |
| Horizontal Reach | 40 METER | Engine Type | Diesel |
| Max Concrete Output | 140 m3/h | Engine Model | |
| Conrete Press. | 70 Bar | Max.Engine Power | 279 kw |
| Barrel Size | 600 L | Max.EngineTorque | 394HP |
| Radio Remote conctrol | concrete pump remote controller | Transmission | Volvo |
| Radio Remote Brand | remote controller HBC 735 | Max. Speeds | 80 km/h |
| Condition | concrete pump but well condition | Total Weight | 32980kg |
| Recent Significant | Excellent condition, low hours | Dimension(L*W*H) | 12981*2490*3867 |
Application
Highway overpasses and tunnels: Highway overpasses must be made of durable, reinforced concrete to support the daily tonnage of traffic that passes over them. Roadway tunnels also must be strong enough not to collapse under the weight of the earth above them. Using a concrete pump makes sure the job gets done efficiently and effectively. Overpasses and tunnels also often involve working with some elevation, and the use of a concrete pump, especially a boom pump for its added lift, makes the job quicker and easier
Here are some of the many benefits of using concrete pumps for your next construction project.
Concrete pumps can pump large volumes of concrete as quickly as a truck mixer can discharge the concrete. Many pumps can pump 30 to 100 cubic metres of concrete per hour. And this quick, precise placement method also ensures a quality pour.
The setup time for concrete pumps is also very fast—arriving on site and pumping concrete within the hour.
Our products are sold all over the world, you can rest assured.
