1. Stability and Durability: adapt and apply the most advanced technologies around the world.
2. Reliability: 10 years of experiences in manufacturing concrete batching plant.
3. Stationary modular structure, fast and easy installation.
4. XDM JS Concrete mixer or Sicoma mixer, Excellent mixing performance with high efficiency and high productivity.
5. Excellent environmental protection, dust collection system and anti-noise design.
| Parameter of HZS60 | |
| Theoretical Production | 60m3/h |
| Mixer Model | JS1000 |
| Mixing Power | 2×18.5Kw |
| Cycle Time | 60s |
| Aggregate Size | ≤80mm |
| Capacity of Grading Station | 1600L |
| Aggregate Bin Volume | 3×9m3 |
| Max.Production Rate of Belt conveyor | 140t/h |
| Max.Production Rate of Spiral Conveyor | 60t/h |
| Discharge Height | 3.8m |
| Installed Capacity | 132Kw |
| Weighing Accuracy of Aggregate | (600-2000)±2%kg |
| Weighing Accuracy of Cement | (150-500)±1%kg |
| Weighing Accuracy of Fly Ash | (150-500)±1%kg |
| Weighing Accuracy of Water | (150-500)±1%kg |
| Weighing Accuracy of Additive | (15-50)±1%kg |
Machine Technical Advantages
1. Our mixing plants adopt integrated structure, complete machine set installation,
so it can move conveniently, and the price is reasonable.
2. The control system is full automatic, and it have function of screen display, matched
storage, compensating fall automaticly, and it can also achieve manual controlling.
3. The aggregate adopts hopper lifting, so it operates steadily.
4. The electric control system adopts Mitsubishi,Omron,Schneider elements..
5. The total equipment used standard components,So it maintain conveniently.
For After-sales, to minimize the downtime, we offer air delivery for the spare parts which are within guarantee within 5 working days. We have professional technician to support trouble clearing and maintenance.
Q: How about the price?
A: We are manufactory, not dealer, so we can give you a lower price than those trade companies can.
Q: Do you provide after-sale service?
A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports.
Q: Do you provide concrete batching plant flow chart?
A: Yes. Our experienced engineers are specialized in designing process flow for various concrete batching plants. We can design the concrete batching plant based on crustomers' particular requirements.
Our products are sold all over the world, you can rest assured.
