2012 Year 3 Axles Concrete Cement Boom Pumping Machine Used Concrete Beton Pump
Operation of Boom
The operation of the cloth arm can be completed by the electric control cabinet or by the remote control.
1. Through the electronic control button and the outrigger multi-way valve, all the outriggers are unfolded (half-extended state is prohibited). Make sure that the whole machine is completely fixed horizontally (the bubbles in the level gauges on both sides should be in the middle).
2. Turn the "manual/remote control" switch on the operation panel of the electric control cabinet to the remote control position; Note: The functions of the remote control buttons are shown in the instruction manual provided with the car.
3. If there is air in the boom hydraulic cylinders and pipelines, there may be a danger of rapid falling when the boom is moved, causing damage to equipment and personnel.
| Concrete Pump Information | Truck information of Concrete Pump | ||
| Type | BOOM CONCRETE PUMPS | Truck Brand | Mercedes Benz |
| Brand Name | Zoomlion | Truck Model | Actros 3341 |
| Pump Model | ZLJ5336THB | Truck Year | 2011 Year |
| Pump Year | 2012 year | VIN. | WDANHC*****8888 |
| Boom Length | 47METER | Axle Config | 3 axle |
| Boom Section | 5 SECTIONS RZ FOLD | Truck Hours | 3000 hours |
| Vertical Reach | 47 METER | Engine Make | Actors |
| Horizontal Reach | 43 METER | Engine Type | Diesel |
| Max Concrete Output | 120/70 m3/h | Engine Model | |
| Conrete Press. | 11/7 Mpa | Max.Engine Power | 294KW |
| Radio Remote conctrol | concrete pump remote controller | Max. Speeds | 80 km/h |
| Condition | concrete pump but well condition | Total Weight | 32870kg |
| Recent Significant | Excellent condition, low hours | Dimension(L*W*H) | 12060*2500*4000 |
| Repairs | Concrete pumps system | Maintenance | Changed all filters |
| Hydraulic System | Engine oil | ||
| Electrical System | Gear box oil | ||
| Changed Spare Parts | Tires | ||
| Checked Boom | Cab | ||
| Changed Seals | Driving testing | ||
