37 Meter Howo New Chassis Sany Brand Second Hand Truck,For Construction
| Model | ZLJ5290THB | |
| Pumping system | Maximum theoretical delivery (m3/h) | 100/60 |
| Concrete maximum outlet pressure (MPa) | 8/15 | |
| Fixed work stress (MPa) | 35 | |
| Pumping frequency (min-1) | 25/14 | |
| Hopper volume (L) | 550 | |
| Feeding height (mm) | 1540 | |
| Hydraulic system type | open | |
| Distribution valve form | S valve | |
| Cylinder bore × stroke (mm) | Φ150×1650 | |
| Concrete bore diameter × stroke (mm) | Φ230×1650 | |
| Hydraulic oil cooling | Air cooled | |
| Recommended slump (cm) | 12~23 | |
| Maximum aggregate size (mm) | 40 | |
| Boom | structure type | 37X-4RZ |
| Maximum fabric height (m) | 36.5 | |
| Maximum cloth radius (m) | 32.15 | |
| Maximum cloth depth (m) | 24.95 | |
| Swing angle | ±270° | |
| Number of arms | 5 | |
| Arm length (mm) | 7280/5920/5670/6880/6750 | |
| Arm angle | 90°/180°/180°/240°/195° | |
| Duct diameter (mm) | 125 | |
| End hose length (mm) | 3000 | |
| Boom minimum opening height (mm) | 7790 | |
| Leg span (front × back × portrait) (mm) | 6190mm×7740mm×6780mm | |
| Chassis and vehicle | Chassis model | Howo Brand |
| Wheelbase (mm) | 5200 | |
| Engine maximum power (kW/(r/min)) | 228/2300 | |
| Engine maximum torque N.m/(r/min) | 1230 /(1200~1800) | |
| engine capacity cc | 6870 | |
| Fuel tank volume L | 300 | |
| Exhaust emission standard | Euro V | |
| Vehicle quality (kg) | 28870 | |
| Overall dimensions (length × width × height) mm | 9840×2530×3905 | |
| other | Lubrication method | Energy-saving automatic lubrication |
| Hydraulic tank volume L | 630 | |
| control method | Manual + remote | |
| Pump maximum pressure MPa | 6 | |
| Water tank capacity (L) | 350 | |
| Concrete pipe cleaning method |
Washing/dry cleaning |
|
