8*4 Zoomlion 50m Concrete Pump Truck Renewed Beton Pump Isuzu Chassis 160m3/H
Category | Unit | ZLJ5400THBK | |
Outline dimension | mm | 13100*2500*4000 | |
Overall weight | kg | 39915 | 39720 |
Brand | / | Zoomlion | |
Model | / | CYH51Y | |
Wheelbase | mm | 4800+1400 | |
Max.power | kW | 287 | |
Emission standard | / | Euro III | |
Theoretical | m³/h | 160 | |
Concrete pumping pressure | MPa | 8 | |
Theoretical pumping times | Times/min | 23~26 | |
Delivery cylinder diameter × stroke | mm | φ260×2000 | |
Reach height | m | 49.1 | |
Reach depth | m | 34.4 | |
Slewing radius | m | 44.2 | |
Slewing angle | ° | ±270 | |
Transfer | / | Rock valve/S valve |
50m Isuzu concrete pump truck is equipped with more efficient skirt valve and S valve pump technology, more stable reversing buffer technology, more reliable full hydraulic reversing technology.
Advantages and highlights:
1.Ultimately Safe Boom.
2. Lower Structure of High Rigidity.
3.Hydraulic System of Outstanding Performance.
4.Effectively reduce emissions with the reversing, vulnerability of longer life.
5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.
6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.
1:What are your main products?
A:Concrete pump truck,concrete pump,concrete line pump,concrete mixer truck,truck-mounted concrete pump,concrete batching plant,concrete pump spare parts
2: What items were repaired?
A: We changed concreye pump truck glasses plate,cutting ring, all weaing parts and etc.
3: How do I know the condition of the concrete pump truck?
A: We will provide a video of the test machine of the pump truck. Before we ship to you, we will test the machine for pumping for 8 hours.
4: What is the minimum order quantity for your concrete pump truck?
A: The MOQ is 1 unit.
5. How can you guarantee quality?
A: Our raw material every node will be inspected strictly.advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.Ensure that each of our customers is satisfied with the pump truck
Q:Can you customize your products?
A:Yes, we will do the customization by requirement without affecting the quality of the products
Q:How long is the warranty period ?
A:We offer 12 months warranty for the machine (main body) from the date of installation finished.
Q:What's the payment method ?
A:We accept L/C, T/T and D/P payment.
