Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141

Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141

Products - Used Concrete Pump Truck
  • High Light

    Zoomlion Used Concrete Pump Truck

    ,

    180M3 Used Concrete Pump Truck

    ,

    Actros 4141 Used Pump Truck

  • Condition
    Used
  • Power Type
    Diesel
  • Dimension(L*W*H)
    14350*2530*4000mm
  • Brand Name
    Zoomlion
  • Weight
    43870kg
  • Power
    300 Kw
  • Marketing Type
    Ordinary Product
  • Video Outgoing-inspection
    Provided
  • Chassis Model
    Actros 4141
  • Max Concrete Output
    80M3/h
  • Place of Origin
    China
  • Brand Name
    Zoomlion
  • Certification
    ISO90001.SAE
  • Model Number
    ZLJ5419THBK
  • Minimum Order Quantity
    1 Unit
  • Price
    Negotiable
  • Packaging Details
    RORO Ship, Cargo Bulk Ship
  • Delivery Time
    7-20 Working Days
  • Payment Terms
    T/T
  • Supply Ability
    10 Units Per Month

Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141

  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
  • Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141
Get Price Contact Now



180M3/H 60m Zoomlion Used Concrete Pump Truck 4 Alex Actors 4141

Main Parameters



Distribution valve

S-valve
Max. Concrete Output m3/h 180
Max. Concrete Pressure bar 90
Delivery Cylinder mm 260
Stroke Length mm 2100
Strokes 1/min 27
Hopper Capacity L 600
Filling height mm 1540
Hydraulic System Closed
Hydraulic oil cooling Double fans
High/Low Press. Switch Manual
Lubrication on pump Automatic
Lubrication on hopper Automatic
GPS Data Manage Optional

Boom Control Valve

Proportional
Number of Arms   6
Folding System   RZ
Max. Reach Vertical m 60
Max. Reach Horizontal m 56
Pipeline DN125/5.5
Slewing Range ±350°
Slewing Motors 2 motors
Remote Control System Radio
Water Pump 20L/min, 60bar
Tool kits with box Standard
• Compact in design, 60m pump mounted on 4-axle truck.
• Efficient pump unit, two Rexroth main pumps gives a big output, easy to use and maintenance.
• Agile placing boom with 6 arms with unfolding height 14m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, it monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components



Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 0Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 1Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 2Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 3Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 4Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 5Zoomlion Used Concrete Pump Truck 180M3/H 60m 4 Alex Actors 4141 6

FAQ

Q: What is your oil pump brand?

A: Germany Rexroth or Korea Kawasaki.



Q: The motor power is the electrical or diesel?

A: Both type. The power of electric type apply to 330V 50Hz.



Q: How about guarantee period?

A: 1 year for non-easy worn parts. We strictly follow the warranty terms.



Q: What is the payment terms?

A: We accept L/C, T/T. 30% by T/T in advance, 70% by T/T before dispatching from factory.
