Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section

  • High Light

    50m Boom Concrete Truck

    ,

    Putzmeister Boom Concrete Truck

    ,

    140m3/H Boom Pump Truck

  • Engine Type
    Diesel
  • Boom Length
    38 M
  • Max. Horizontal Conveying Distance
    34 M
  • Boom Section
    4 Boom
  • Power
    265 KW
  • Max Concrete Output
    140 M3/h
  • Concrete Pressure
    70 BAR
  • Chassis Model
    Isuzu
  • Total Weight
    26000KG
  • Dimensions(L*W*H)
    12154*2490*3948mm
  • Place of Origin
    Germany
  • Brand Name
    Putzmeister
  • Certification
    ISO90001.SAE
  • Model Number
    SG5267THB
  • Minimum Order Quantity
    1 unit
  • Price
    Negotiable
  • Packaging Details
    RORO ship, Cargo bulk ship
  • Delivery Time
    7-20 working days
  • Payment Terms
    T/T
  • Supply Ability
    10 units per month

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section



Working conditions



The optimal environment temperature of machine working condition is 0~40℃. When it is above 40℃ or be low 0℃, it is necessary to contact the manufacturer for advice of maintenance.

Max.permissible wind speed of the whole vehicle in working condition is 50km/h(6grade). When the wind speed exceeds the value, the operation should be stopped and the placing boom should be retracted to transporting condition.
.



BRAND
PUTZMEISTER
Condiiton
used but good running
Model
38M
Original
CHINA
Weight
26ton
location
Changsha,China
Color
Original color
Max. travel speed
5.5km/h
Power Measured
2000rpm
Pump type
Remote control
Hydraulic folding
Engine
Izusu brand
Water Cooling
Direct inject engine
6 cylinders
Cabin
Left steering
2 Seats +1 mini rest bed
suitable for 2 drivers .
Chassis
Izusu brand
6x4 axle
Left hand drive
Rustless /strong enough
Tyres
10tyres
Good condition original tyres (no damaged tyres )
Boom
Hydraulic folding
Remote control
Maintenance
Engine /pump /chassis
Repaint by client design



Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 0

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 1

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 2

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 3

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 4

Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 5



Putzmeister 140m3/H 50m Boom Concrete Truck Heavy Duty With 5 Boom Section 6

1: What are your main products?
A: Concrete pump truck,concrete pump,concrete line pump,concrete mixer truck,truck-mounted concrete pump,concrete batching plant,concrete pump spare parts

2: What items were repaired?
A: We changed concreye pump truck glasses plate,cutting ring, all weaing parts and etc.

3: How do I know the condition of the concrete pump truck?
A: We will provide a video of the test machine of the pump truck. Before we ship to you, we will test the machine for pumping for 8 hours.

4: What is the minimum order quantity for your concrete pump truck?
A: The MOQ is 1 unit.

5. How can you guarantee quality?

A: Our raw material every node will be inspected strictly.advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.Ensure that each of our customers is satisfied with the pump truck
