180m3/H 52m Boom Concrete PumpTruck Heavy Duty With 6 Boom Section
One Button Stabilization Technology
The one button stabilization technology quickly dampens any boom movement resulting from repositioning the boom. This allows precise positioning of the end hose.
Boom Anti Vibration Technology
The boom anti vibration technology reduces vibration during pumping by 50% allowing less movement and greater control of the end hose.
Energy Saving Technology
With cycle times of up to 29 per minute (at 12MPa), pump efficiency is increased up to 25% while fuel consumption is decreased by up to 10%.
Anti Overswing Technology
By adopting our new swing brake technology, the boom's overswing amplitude is reduced by 60%
Fault Self Diagnostic Technology
Continually monitors more than 200 aspects of the system during operation. Faults are displayed on the monitor. Review of the detected faults can reduce troubleshooting time by 70%.
Smart Boom System
One Button Boom Extend/Retract
Press upward on the boom extend/retract button to extend the boom or press downward to retract the boom automatically.
Coordinated Section Operation
The boom can be rapidly and accurately repositioned by coordinating the movement the first and second sections
Safety Technology
Boom Overload Protection Technology
Relief valves are mounted on the boom cylinder counterbalance valves. These valves will release pressure in the event of excessive boom load to prevent damage to the boom.
Hopper Screen Interlock Technology
As an operator protection measure, the pump will automatically stop when the hopper screen is opened.
Hydraulic Oil Level Monitoring
The oil level in the hydraulic reservoir is continually monitored. If the level drops below a preset level, an alarm will sound and the pump will be stopped to prevent damage to the hydraulic system.
| Concrete Pump Information | Truck information of Concrete Pump | ||
| Type | BOOM CONCRETE PUMPS | Truck Brand | Mercedes Benz |
| Brand Name | SY | Truck Model | Actros 4141 |
| Pump Model | SYM5350THB | Truck Year | 2019 Year |
| Pump Year | 2019year | VIN. | WDANHC***** |
| Boom Length | 52METER | Axle Config | 4 axle |
| Boom Section | 6 SECTIONS RZ FOLD | Truck Hours | 3000 hours |
| Vertical Reach | 52 METER | Engine Make | Actros |
| Horizontal Reach | 48 METER | Engine Type | Diesel |
| Max Concrete Output | 180 m3/h | Engine Model | |
| Conrete Press. | 12 Mpa | Max.Engine Power | 320 KW |
| Radio Remote conctrol | concrete pump remote controller | Max. Speeds | 80 km/h |
| Condition | concrete pump but well condition | Total Weight | 35000KG |
| Recent Significant | Excellent condition, low hours | Dimension(L*W*H) | 12130*2550*4000mm |
| Repairs | Concrete pumps system | Maintenance | Changed all filters |
| Hydraulic System | Engine oil | ||
| Electrical System | Gear box oil | ||
| Changed Spare Parts | Tires | ||
| Checked Boom | Cab | ||
| Changed Seals | Driving testing | ||
1: What are your main products?
A: Concrete pump truck,concrete pump,concrete line pump,concrete mixer truck,truck-mounted concrete pump,concrete batching plant,concrete pump spare parts
2: What items were repaired?
A: We changed concreye pump truck glasses plate,cutting ring, all weaing parts and etc.
3: How do I know the condition of the concrete pump truck?
A: We will provide a video of the test machine of the pump truck. Before we ship to you, we will test the machine for pumping for 8 hours.
4: What is the minimum order quantity for your concrete pump truck?
A: The MOQ is 1 unit.
5. How can you guarantee quality?
A: Our raw material every node will be inspected strictly.advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.Ensure that each of our customers is satisfied with the pump truck
Our products are sold all over the world, you can rest assured.
