Concrete Mixer With Pump, it is widely used to mixing and pumping the concrete for construction project. What's more, mining, tunnel, culvert, subway, hydropower engineering, underground excavation engineering etc
concrete mixer pump construction operation system can be used in all automated, all material mixing, high pressure pumping as one. Double cylinder hydraulic pumping system, hydraulic system greatly enhance the stirring concrete pump overall reliability and ensure pump strive foolproof work under harsh conditions.
Techincal Parameter of BANGBO Concrete Mixer Pump
| DISTRIBUTE VALVE | S value |
| Theoretical output | 40m3/h |
| Actual output | 25m3/h |
| Max Pressure | 8Mpa |
| Delivery Cylinder | 200MM |
| Oil tank capacity | 170L |
| Drum rotary speed | 15r/m |
| Diameter of drum | 1440mm |
| Engine brand | weicai , cummins, can be customized. |
| Total Power | 62kw |
| Max dia.of aggregates | Cobble:40,macadam:30 |
| Outline dimension(L*W*H) | 5100*2200*3100 mm |
| Total weight | 5500 kg |
| Outlet opening Diamater | 180MM |
| Product Keywords | mixer machine 0.5m3,automatic concrete mixer,js500 concrete mixer |
Q1: How many types of bangbo concrete mixer pumps do you have?
A: The motor ,diesel and electric.
If you need electric motor one, please let us know your power situation, such as in China, it is 380Voltege & 50 HZ. If you need diesel motor concrete mixer pump, the brand of diesel engine you like, it is Cummins or Deutz or Chinese Weichai,yuchai ?
Q1: How long and high is the pump distance?
A: We can provide 2 floors to 12 floors. Please let us know the vertical and horizontal delivery distance should reach. Or please let me know the tall building's total height.
Q3: How to guarantee customers get the goods smoothly after they pay?
A: We joined the trade assurance. you can place the order by trade assurance,and the deposit will given to Alibaba. if we don't delivery products on time, the deposit will return to you.
Our products are sold all over the world, you can rest assured.
