BANGBO Concrete Stationary Pump

BANGBO Concrete Stationary Pump

  • Highlight

    16MPa Concrete Stationary Pump

    ,

    BANGBO Concrete Stationary Pump

    ,

    16MPa diesel concrete mixer pump

  • Engine Type
    Diesel
  • Theoretical Output
    80 Cubic PER HOUR
  • Max Pressure
    16MPa
  • Engine Rated Power/speed
    176/2300 KW/rpm
  • Max. Vertical Conveying Distance
    130M
  • Max. Horizontal Conveying Distance
    400M
  • Total Power
    176kw
  • Made Year
    2021
  • Total Weight
    7500 Kg
  • Dimensions(L*W*H)
    6900*2000*2700mm
  • Place of Origin
    China
  • Brand Name
    BANGBO
  • Certification
    ISO90001.SAE
  • Model Number
    HBT80.16.176RS
  • Minimum Order Quantity
    1 unit
  • Price
    Negotiable
  • Packaging Details
    RORO ship, Cargo bulk ship
  • Delivery Time
    7-20 working days
  • Payment Terms
    T/T
  • Supply Ability
    10 units per month

BANGBO Concrete Stationary Pump

Little Hour 80M3/H Stationary Cement Pump New Concrete Pump In Truck



Benefits & features





Advanced hydraulic system



Pressure difference sensing & reversing hydraulic system
BANGBO trailer-mounted concrete pump adopts pressure difference sensing & reversing technology, in addition to electro-hydraulic proportional buffering technology. Therefore, the pump has not only features like self-cyclic impurities filtering by open-type system, hydraulic oil’s high cleanliness, and low temperature etc., but also characteristics like close-type system’s small reversing impact. That helps improve the system efficiency to the maximum extent, mitigate ab rasion between parts, prolong the equipment’s service life, and reduce the maintenance cost.

Large-flow high-efficiency main valve system
The system adopts high-pressure, large-flow, and electro-hydraulic precision control main
valve, as well as integrated valve bank with optimized runner design and layout. Due to this, the
system features short reversing time, small pressure loss, low temperature, and high reliability.

Automatically retracted double-piston
Make two concrete pistons retract into the water tank only by using one button. Due to this, the time for replacement and maintenance is reduced by half, and daily maintenance is more convenient.

Technical Parameters
Pump Model
HBT80.16.176RS
Engine type
Diesel type
Distribution Valve
S-valve
Theoretical output
90m3/h
Max Pressure
18Mpa
Engine Rated Power
199kw
Rated Speed
2300r/m
Outlet opening Diamater
180MM
Engine brand
WeiChai
Max Hprizontal Distance
600
Max Vertical Distance
220
Hopper volume*feeding height
800*1400
Maximum aggregate size
Cobble:50, macadam:40
Weight
7500kg
Dimensions(L*W*H)
6900*2000*2700 mm

concrete pump concrete pump concrete pump concrete pump concrete pump concrete pump concrete pump concrete pump concrete



BANGBO Concrete Stationary Pump 0

BANGBO Concrete Stationary Pump 1BANGBO Concrete Stationary Pump 2BANGBO Concrete Stationary Pump 3BANGBO Concrete Stationary Pump 4BANGBO Concrete Stationary Pump 5BANGBO Concrete Stationary Pump 6



BANGBO Concrete Stationary Pump 7

Q: How is the quality of your products?

A: our machines are manufactured strictly according to national and intemational standards, and we take a test oneach equipment before delivery You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection.



Q: How about the price?

A: We are factory and be able to give you the lowest price than market one, and we have a policy that for saving timeand absolutely honest business attitude, we quote as low as possible for any customer, and discount can be given according to quantity.



Q: Do you provide after-sale service?

A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems.
